Epson PLQ-50M

Magnetic stripe position
A Magnetic stripe minimum area
B Seam or Right edge
Single sheets
Front Ejection Rear Ejection
Minimum Maximum Minimum Maximum
Width (mm)
(inch)
65
2.6
245
9.6
65
2.6
245
9.6
Length (mm)
(inch)
67
2.64
297/(450)*
11.69/(17.72)*
142
5.59
297/(450)*
11.69/(17.72)*
PLQ-50/PLQ-50CS/PLQ-50M/PLQ-50CSM/PLQ-50CSK User’s Guide
Product Information 79
