Epson PLQ-50M

Recordable formats IBM3604, DIN/ISO, ISO7811, IBM4746, ANSI, HT-2751-CIZ,
ISO8484
Recorded track width 9.7 mm
Read track width 1.1 mm
Speed of medium 340 mm/second
Number of retries 1 or 3
Field duplication YES or NO
Recordable area
Back Cover:
*: Magnetic stripe area
**: Recordable area
F (max) G H (min) I J (max)
DIN/ISO, ANSI
12.5 13.9 15.5 9.5 85
IBM3604
8.9 10.4 11.9 10.4 81.3
ISO7811
8.9 10.4 11.9 14.8 —
IBM4746
8.9 10.4 11.9 9.8 —
ISO8484
12.5 13.9 15.3 9.5 85
PLQ-50/PLQ-50CS/PLQ-50M/PLQ-50CSM/PLQ-50CSK User’s Guide
Product Information 83
