Settings item Setting/Additional Explanation
Advanced Paper Settings
Confirm ICC profile Displays the ICC profile name.
This item is only displayed when the PS option is connected.
Confirm Color Density Displays the Color Density.
This item is only displayed when the PS option is connected.
Paper Thickness 0.01 - 1.50 mm (0.4 - 59.1 mil) (0.01 mm units)
Platen Gap Auto, 1.2, 1.6, 1.9, 2.1, 2.4
Top Margin 3 mm, 15 mm, 20 mm, 45 mm
If the margin at the leading edge of the paper is small, colors may be
uneven depending on the paper and printing environment. If this occurs,
print a larger margin at the leading edge of the paper.
Bottom Margin 3 mm, 15 mm
Margin Between Pages Standard, 6 mm, 30 mm, 65 mm
Paper Suction -4 - +3
Thin or soft paper may not be fed correctly. If this occurs, reduce the
setting.
Back Tension Standard, High, Extra High
Adjust this when paper gets wrinkled during printing.
Drying Time Drying Time per Pass, Drying Time per Page
You can set the drying time for each print head movement (pass) or the
drying time for each page.
Paper Size Check On, Off
When this is set to On, the width of the loaded paper is automatically
detected.
Auto Cut Use Paper Source Settings, Off
Skew Reduction On, Off
Select whether to enable (On) or disable (Off) paper skew reduction while
printing on paper.
Roll Core Diameter 2inch, 3inch
Set the paper core size for the roll paper being loaded.
Lateral Feed Adjustment On, Off
Set this to On to correct differences in the left or right of the paper feed.
Paper Eject Roller Auto, Use, Do Not Use
Paper Feed Offset -1.0 - +1.53%
This item is only displayed for Custom Paper Setting.
SC-P9500 Series/SC-P7500 Series User's Guide
Menu List
108
