Item Parameter Explanation
Media Tension Lv1 Increase tension if creases appear in the media during printing. The higher
the value, the greater the tension.
Lv2
Lv3
Lv4
Media Suction
0 to 10 (4
*
)
When media is waved on the platen, increase the Media Suction. The
higher the value, the greater the suction.
If graininess or out-of-focus characteristics are detected in printing results
obtained using thin or soft media or if the media is not fed normally,
reduce the Media Suction.
Head Movement
Data Width
*
Choose the range in which the print head moves during printing.
Data Width restricts print head movement to the printed area. Restricting
the extent of print head movement increases print speed.
If Printer Full Width is selected, the print head will move the full width of
the largest media supported by the printer. Select this option for more
even print results with less variation.
Printer Full
Width
Multi Strike Printing
OFF
*
Choose the number of times each line is printed.
To carry out high-density printing using backlight films, increase the
frequency.
2 to 8
Feed Speed Limiter ON
OFF is recommended in normal circumstances.
Set this to ON if media sticks or wrinkles, or tears easily when printing on
thin media.
When this is set to ON, print speed slows down.
OFF
*
Pressure Roller Load Low If the following occurs when printing, you may be able to avoid it by
changing to a load that reduces the pressure on the rollers (for example:
Medium to Low).
❏ When there is wrinkling around the pressure rollers.
❏ When there are stains due to head striking.
❏ When stains on the roller stick to the media.
Medium
Heavy
Remove Skew ON Select whether or not (ON or OFF) to perform skew correction for media
loaded in the printer. The default setting of ON is recommended in most
situations. Set this to OFF if the media shows traces from the rollers due to
skew corrections.
OFF
Take-Up
*1
Standard
*
Normally, use as Standard.
If the media sticks while printing on media that builds up static easily and
cannot be taken up correctly because of problems, such as waving, set this
to strength tension. If the problem persists, even when setting this to
strength tension, use media that does not build up static easily.
strength
tension
Periodical Cleaning
Auto
*
Performs head cleaning at the most suitable time according to the media settings.
If the specified time for periodic cleaning is reached during printing, head cleaning is per‐
formed after printing is complete.
Manual
Manual is performed when specifying the frequency according to the usage.
SC-S80600 Series/SC-S80600L Series/SC-S60600 Series/SC-S60600L Series/SC-S40600 Series User's Guide
Using the Control Panel Menu
106
