Paper Size Forward (a) Backward (b)
A2 185mm 220mm
A1 432mm 467mm
24 × 30 inch 353mm 388mm
30 × 40 inch 607mm 642mm
Loading documents
A
Align the loading guide with the document
loading position.
To ensure that the document is not fed on an
angle, we recommend inserting the long side of
the document.
B
With the side of the document to be read facing
up, align the right edge of the document with the
loading guide.
C
Insert the document horizontally so that the
entire edge touches all inner rollers.
If the edge touches the roller, the document is fed
to the read start position automatically. After
automatic loading starts, release your hand and
do not obstruct the loading of the document.
SC-T7200 Series/SC-T5200 Series/SC-T3200 Series/SC-T7200D Series/SC-T5200D Series User's Guide
Copying and Scanning
75
