Epson Stylus CX4600 Service Manual

EPSON Stylus CX3500/CX3600/CX3650/CX4500/CX4600 Revision A
DISASSEMBLY AND ASSEMBLY Disassembly 118
4.3 Disassembly
The flowchart below shows step-by-step disassembly procedures. When disassembling each unit, refer to the page number shown in the figure.
Figure 4-1. Disassembling flowchart
START
“4.3.1 Document Cover” (p.119)
“4.3.4 Scanner Unit” (p.121)
“4.3.5 Panel Unit” (p.126)
“4.3.6 Housing Upper” (p.127)
“4.3.8 Printer Mechanism” (p.130)
“4.3.11 Main Board Unit” (p.136)
“4.3.17 Carriage Unit” (p.149)
“4.3.20 EJ Frame Unit” (p.154)
“4.3.22 Paper Guide Front Unit”
(p.157)
“4.3.23 PG Sensor” (p.158)
“4.3.24 PF Roller Unit” (p.159)
“4.3.19 Front Frame” (p.153)
“4.3.14 CR Guide Frame” (p.146)
“4.3.12 ASF Unit” (p.141)
“4.3.13 Holder Shaft Unit” (p.143)
“4.3.9 PS Board Unit” (p.133) “4.3.10 Waste Ink Pads” (p.134)
“4.3.16 PF Motor” (p.148)
“4.3.18 Paper Guide Upper Unit”
(p.152)
“4.3.3 Stacker Assy.” (p.120)
“4.3.7 Print Head” (p.128)
“4.3.21 Ink System Unit” (p.156)
“4.3.2 Paper Support Assy.”
(p.120)
T To remove the “Ink System Unit”, all parts shown
in the red boxes need to be removed.
T To remove the “Paper Guide Front Unit”, all parts
shown in the red boxes need to be removed.
“4.3.15 CR Motor” (p.147)

Epson Stylus CX4600 Specifications

Printer Specifications

printing technology	CMYK drop-on-demand Micro Piezo ink jet
ink type	DURABrite Ink
maximum resolution	5760 x 1440 optimized dpi

Scanner Specifications

scanner type	Color flatbed
scan area maximum	8.5" x 11.7"
resolution optical	600 dpi

Copier Specifications

copy speed black text	13 cpm
copy speed color text	13 cpm
copy size	4" x 6" Letter (8.5" x 11")

Dimensions and Weight

dimensions	16.9" x 13.5" x 6.7"
weight	18.3 lb
weight with ink cartridges	18.3 lb
