8.3.2 Required Adjustments
The table below lists the required adjustments depending upon the parts being repaired
or replaced. Find the part(s) you removed or replaced, and check which adjustment(s)
must be carried out.
Note : <Meaning of the marks in the table>
“O” indicates that the adjustment must be carried out. “O
*
” indicates that the adjustment
is recommended. “---” indicates that the adjustment is not required.
If you have removed or replaced multiple parts, make sure to check the required
adjustments for the all parts. And when multiple adjustments must be carried out, be
sure to carry out them in the order given in the “Priority” row.
C H E C K
P O I N T
See Chapter 5 "ADJUSTMENT" for the adjustments other than
" 8.3.3 Touch Panel Calibration (p160)" and " 8.3.4 Touch Panel
Operation Check (p160)".
Table 8-2. Adjustment Items
Priority 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20
PG adjustment
Touch Panel calibration
Touch Panel operation check
EEPROM data copy
Initial setting
USB ID input
Head ID input
Waste ink pad counter
Ink charge
Initialize
PF deterioration offset
Disenable
PF deterioration offset
Top margin adjustment
Head angular adjustment
Bi-D adjustment
First dot position adjustment
PW adjustment
PF/EJ adjustment
BRS adjustment
PFP adjustment
CR motor heat
protection control
Panel Unit
Remove
-- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- --
Replace
-- O O -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- --
ASF Unit
Remove
-- -- -- -- -- -- -- -- -- -- -- O -- -- O -- O -- O --
Replace
-- -- -- -- -- -- -- -- -- -- -- O -- -- O -- O O --
CR Motor
Remove
-- -- -- -- -- -- -- -- -- -- -- -- -- O
*
-- -- -- -- -- --
Replace
-- -- -- -- -- -- -- -- -- -- -- -- -- O
*
-- -- -- -- -- O
Upper
Paper Guide
Remove
-- -- -- -- -- -- -- -- -- -- -- O -- -- -- -- O O O --
Replace
-- -- -- -- -- -- -- -- -- -- -- O -- -- -- -- O O O --
Printhead
Remove
O--------------------OOOOOOOO--
Replace
O -- -- -- -- -- O -- O -- -- O O O O O O O O --
Main Board Unit
Remove
-- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- --
Replace
(Read OK)
-- -- -- O -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- O
Replace
(Read NG)
-- O O -- O O O
O
(Ink Pads
must be
replaced)
----OOOOOOOOOO
Adjustment Item
Part Name
