Epson Stylus Pro GS6000 Quick Reference Guide

2 | Loading Media in the Epson Stylus
®
Pro GS6000
4. Release both levers, move the center of the roll to the d mark, and lock the levers again.
5. Open the front cover, then carefully feed the media into the slot and through to the front and out
about 3 ft (1 m).
6. Turn the roll backward to remove any slack
and make sure the edge of the media does not
extend beyond the media limit line.
Center
mark
Lever is
behind roll
Media limit
line

Epson Stylus Pro GS6000 Specifications

General

Color	Yes
Maximum resolution	1440 x 1440 DPI
Print head nozzles	360 x 8
Number of print cartridges	8
Cut sheets	No
Maximum print size	-
Maximum roll diameter	170 mm
Paper tray media types	Banner, Glossy paper
Display	LCD
Country of origin	Japan
Sound pressure level (printing)	70 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100/1000Base-T(X) Mbit/s
Ethernet interface type	Gigabit Ethernet
Compatible operating systems	Windows Vista/XP, Macintosh 10.5.x
Minimum system requirements	2.8 GHz Intel Core 2 Duo, 4GB RAM
Power requirements	AC 100 –240 V, 50 – 60 Hz
Power consumption (active)	680 W
Power consumption (standby)	48 W
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	5 - 85 %
Operating relative humidity (H-H)	40 - 50 %
Package depth	2960 mm
Package width	1160 mm
Package height	1225 mm
Package weight	435093 g
Quantity per pack	1 pc(s)

Weight and Dimensions

Size (imperial)	64 \
Dimensions (WxDxH)	2698 x 943 x 1267 mm
