Epson SureColor F2000 Series User Manual

Adjusting the Angle of the Fixing Lever
Parent topic: Basic Printing
Replacing the Platen
You may need to replace the platen, depending on the size of the T-shirt.
Note: There are five platen sizes: extra small, small, medium, large, and sleeve. The medium size platen
(standard) is supplied with the printer.
1. If the platen is not in the forward position, press the moveable base button to move the platen
forward.
2. Hold the left and right sides of the platen and lift it up.
39

Epson SureColor F2000 Series Specifications

General

Maximum Print Resolution	1440 x 1440 dpi
Maximum Print Size	16" x 20"
Ink Colors	Cyan, Magenta, Yellow, Black, White
Operating System Compatibility	Windows, macOS
Connectivity	USB 2.0, Ethernet
Printer Type	Direct-to-Garment
Ink Configuration	CMYK + White
Media Width	Up to 16 inches
Operating Temperature	59° to 95°F (15° to 35°C)
Operating Humidity	20% to 80%
Print Technology	Epson PrecisionCore® TFP® Print Head
