Epson TM-T70II-DT User Manual

TM-T70II-DT User’s Manual 10
Specifications
* Capacity of SATA SSD and operating system differ depending on the model.
Item Specification
CPU High model: Intel
®
Atom™ N2800 (1 MB Cache, 1.86 GHz)
Low model: Intel
®
Atom™ N2600 (1 MB Cache, 1.6 GHz)
Memory Main memory High model: 4 GB, DDR3-1066 SO-DIMM slot
Low model: 2 GB, DDR3-800 SO-DIMM slot
BIOS ROM SPI Flash 4 MB
Chip set Intel
®
MN10
Video controller Built-in CPU
Backing storage SATA SSD (16 GB or more)*
Interface Ethernet 10BASE-T/100BASE-TX/1000Base-T 1port (RJ-45)
Support Wake On LAN
Network boot
USB External: x 6 (Compliance: USB 2.0)
Serial × 1 (D-sub 9 pin male)
VGA × 1 (D-sub 15 pin female)
DisplayPort
(only for the high
model)
× 1 (Standard displayport connector 20 pin female)
Drawer-kick × 1 (RJ12 6 pin)
Audio functions Sound output to the built-in speaker
External line-out
RTC/CMOS Backup battery Lithium battery for RTC backup
Speaker Built-in monaural speaker
Printer unit Print method Thermal line printing
Print speed 250 mm/s
Software BIOS AMI BIOS (ACPI 2.0/APM 1.2/Plug&Play-ready)
Operating system* Windows Embedded POSReady7, Windows Embedded
POSReady 2009, or Linux
®
based on openSUSE
Device control
software
ePOS-Device
USB port controller (thin-client connection supported)
Power supply Dedicated AC adapter (AC adapter,T [Model: M284A])
DC 24 V, 4.2 A
Current consumption 13 w (when not printing)/47 w (when printing)
Temperature Operating: 5 to 40°C {41 to 104°F}
Storage: –10 to 50°C {14 to 122°F}
Humidity Operating: 10 to 90 %RH (No condensation)
Storage: 10 to 90 %RH (No condensation)
Overall dimensions 172 × 290 × 114 mm {6.77× 11.42 × 4.49"} (W × D × H)
(Connector cover included)
Mass Approx. 2.8 kg {6.17 lb}

Epson TM-T70II-DT Specifications

General

Type	POS printer
Character size	0.99 x 2.4 mm
Print technology	Thermal
Maximum resolution	180 x 180 DPI
Product color	Black
Maximum roll diameter	83 mm
USB connector	USB Type-A
Serial interface	Yes
Standard interfaces	Ethernet, RS-232, USB 2.0, VGA
Serial interface type	RS-232
Connectivity technology	Wired
Ethernet LAN (RJ-45) ports	1
Safety	TUV
RAM capacity	4 GB
Certification	CE, EN55022 Class A
Country of origin	China
Built-in processor	Atom N2800 1.86GHz
Storage temperature (T-T)	-10 - 50 °C
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Wi-Fi	No
Ethernet LAN data rates	10, 100 Mbit/s
Pallet width	800 mm
Pallet height	2005 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pallet	84 pc(s)
Quantity per pallet (UK)	112 pc(s)
Quantity per pallet layer	12 pc(s)
Quantity per pallet layer (UK)	16 pc(s)
Package depth	275 mm
Package width	237 mm
Package height	265 mm
Package weight	4420 g
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	290 mm
Width	172 mm
Height	114 mm
