Epson TM-U200 Series

10 TM-U200 Series User’s Manual
English
* indicates value with DIP switch 2-1 ON
ANK: Alphanumeric characters
lps: lines per second
Specifications: TM-U200 Models A, B, D
Printing method
Serial impact dot-matrix
Printing direction
Bidirectional logic seeking
Printing width
63.34 mm {2.49"}, 400 dot positions
Characters per line
(default)
7
×
× ×
×
9 Font
: 40,
9
×
× ×
×
9 Font
: 33,
16
×
× ×
×
16 Kanji
: 25,
7
×
× ×
×
27 Thai
: 40,
9
×
× ×
×
27 Thai
: 33
Character size 7
×
××
×
9 Font
ANK: 1.2
×
3.1 mm Graphics: 1.7
×
3.1 mm (1.6
×
3.1 mm*)
9
×
××
×
9 Font
ANK: 1.6
×
3.1 mm Graphics: 2.0
×
3.1 mm (1.9
×
3.1 mm*)
16
×
××
×
16 Kanji
: 2.7
×
2.7 mm
7
×
××
×
27 Thai
: 1.2
×
9.5 mm
9
×
××
×
27 Thai
: 1.6
×
9.5 mm
Number of characters
Alphanumeric characters: 95; International characters: 32
Graphics:128
×
8 character tables
(Multilingual models have 11 character tables and support for one
of the following: Japanese Kanji, Chinese Kanji, Taiwanese Kanji, or
Thai characters)
Print speed
Approx. 3.5 lps (40 column, 16 cpi); 6.4 lps (16 column, 16 cpi)
Not including data transfer and processing time.
Two color or red color printing reduces the speed.
Paper feed speed
Approx. 106 mm/s {approx. 4.17"/s} continuous paper feed
Line spacing (default)
4.23 mm {1/6"}
Ribbon cassettes
ERC-38 (P) Purple Life: 4,000,000 characters
ERC-38 (B) Black Life: 3,000,000 characters
ERC-38 (B/R) Black/Red Life: Black 4,000,000/Red 750,000 characters
Life based on continuous printing at 25°C {77°F}
Paper roll width
76 mm: ± 0.5 {3" ± 0.02}
Interface
RS-232C or Bi-directional parallel
Receive buffer
1 KB or 40 bytes (Multilingual: 512 KB or 40 bytes)
DKD Function
2 drives
Power supply
+24 ~ +34 VDC
Current consumption
Operating: 43 W avg. (except drawer kick-out), Standby: 6 W avg.
Life
Mechanism: 7,500,000 lines
Print head: 150 million characters
Autocutter: 800,000 cuts
MTBF
180,000 hours
MCBF
18,000,000 lines
Temperature
Operating: 0 to 50°C {32 to 122°F}
Storage: –10 to 50° C {14 to 122° F}
Humidity
Operating: 10 to 90% RH (no condensation)
Storage: 10 to 90% RH (no condensation)
Overall dimensions
Type A
160
×
160
×
295 mm {6.3
×
6.3
×
11.6"} (H
×
W
×
D)
Type B
150
×
160
×
248 mm {5.9
×
6.3
×
9.8"} (H
×
W
×
D)
Type D
133
×
160
×
248 mm {5.2
×
6.3
×
9.8"} (H
×
W
×
D)
Weight (mass)
Type A
2.5 kg {5.5 lb},
Type B
2.5 kg {5.5 lb},
Type D
2.2 kg {4.85 lb}
