TM-U200 Series User’s Manual 7
English
6.
Type A only
: When using 2-ply roll paper, insert the end of the
paper into the paper take-up spool as shown below. Be sure
that length of dimension A is between 40 and 60 mm (1.58 and
2.36 inches) and the left side of the paper is aligned with the
spool’s flange, which is indicated by the arrow in illustration
9
below.
7. Insert the journal take-up spool in the printer, as shown in
illustration
10
, and cut the receipt paper.
8. Close the autocutter by using the tab. Be sure to check again
that the left side of the paper is aligned with the spool’s flange;
then close the printer cover.
Troubleshooting
No lights on the control panel
Check the power supply cable connections and the power outlet.
ERROR
light flashing with no printing (and no paper jam)
Printing stops if the head overheats and resumes when it cools.
Turn the printer off, and after 10 seconds, turn it back on.
Removing jammed paper
Follow these steps to clear a paper jam:
CAUTION:
The print head becomes very hot during printing. Allow it to
cool before you reach into the printer.
1. Open the printer cover.
A
910
To Next Page
