Page #12 background imageLoading...
Page #12 background image
Additional Components
Depending on how you plan to use the projector, you may need to obtain the following additional
components:
To receive an S-Video signal, you need an S-Video cable compatible with your device. See your local
computer or electronics dealer for purchase information.
To receive a component video signal, you need a D-sub, 15-pin, component-to-VGA video cable. You
can purchase one from Epson or an authorized Epson reseller.
To receive an HDMI signal, you need a compatible HDMI cable. See your local computer or
electronics dealer for purchase information.
Note: To connect a Mac that includes only a Mini DisplayPort, Thunderbolt port, or Mini-DVI port for
video output, you need to obtain an adapter that allows you to connect to the projector's HDMI port.
Contact Apple for compatible adapter options. Older Mac computers (2009 and earlier) may not
support audio through the HDMI port.
To project with audio from certain ports, you may need a commercially available audio cable
compatible with your device. See your local computer or electronics dealer for purchase information.
To connect a Mac that includes only a Mini DisplayPort, Thunderbolt port, or Mini-DVI port for video
output to the projector's VGA video port, you need to obtain an adapter. Contact Apple for compatible
adapter options.
Parent topic: Projector Features
Optional Equipment and Replacement Parts
You can purchase screens, other optional accessories, and replacement parts from an Epson authorized
reseller. To find the nearest reseller, call 800-GO-EPSON (800-463-7766). Or you can purchase online
at www.epsonstore.com (U.S. sales) or www.epson.ca (Canadian sales).
Epson offers the following optional accessories and replacement parts for your projector:
Option or part Part number
Genuine EPSON Replacement lamp (ELPLP67) V13H010L67
Air filter replacement set (2 filters; ELPAF32) V13H134A32
EPSON DC-06 document camera (ELPDC06) V12H321005
EPSON DC-11 document camera V12H377020
12

Table of Contents

Other manuals for Epson VS220

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Epson VS220 and is the answer not in the manual?

Epson VS220 Specifications

VS220

Display IconDisplay
pixel number480, 000 dots (800 x 600) x 3
color brightness2700 lumens
white brightness2700 lumens
aspect ratio4:3
native resolution800 x 600 (SVGA)
resize support640 x 480 (VGA), 1024 x 768 (XGA), 1280 x 800 (WXGA), 1680 x 1050 WSXGA+
Lamp IconLamp
lamp typeE-TORL 230 W UHE
lamp life (eco mode)5000 hours
lamp life (normal mode)4000 hours
Projection IconProjection
throw ratio range1.45 – 1.96
size (projected distance)23" – 350" (0.87 – 10.5 m)
keystone correctionVertical: Auto ± 30 degrees, Horizontal: Manual
Power and Operating IconPower and Operating
power supply voltage100 – 240 V ±10%, 50/60 Hz
power consumption (normal mode)283 W
power consumption (eco mode)234 W
operating temperature41 ˚ to 95 ˚F (5 ˚ to 35 ˚C)
fan noise (normal mode)37 dB
fan noise (eco mode)29 dB
Physical IconPhysical
dimensions (including feet)11.6" x 9.0" x 3.1"
dimensions (excluding feet)11.6" x 9.0" x 3.0"
weight5.1 lb

VS320

Display IconDisplay
pixel number786, 432 (1024 x 768) x 3
color brightness2700 lumens
white brightness2700 lumens
aspect ratio4:3
native resolution1024 x 768 (XGA)
resize support640 x 480 (VGA), 800 x 600 (SVGA), 1280 x 960 (SXGA2), 1280 x 1024 (SXGA3), 1440 x 900 (WXGA+), 1400 x 1050 (SXGA+), 1600 x 1200 (UXGA)
Lamp IconLamp
lamp typeE-TORL 230 W UHE
lamp life (eco mode)5000 hours
lamp life (normal mode)4000 hours
Projection IconProjection
throw ratio range1.48 – 1.77
size (projected distance)30" – 300" (0.76 – 7.62 m)
keystone correctionVertical: Auto ± 30 degrees, Horizontal: easy-slide
Power and Operating IconPower and Operating
power supply voltage100 – 240 V ±10%, 50/60 Hz
power consumption (normal mode)283 W
power consumption (eco mode)234 W
operating temperature41 ˚ to 95 ˚F (5 ˚ to 35 ˚C)
fan noise (normal mode)37 dB
fan noise (eco mode)29 dB
Physical IconPhysical
dimensions (including feet)11.6" x 9.0" x 3.1"
dimensions (excluding feet)11.6" x 9.0" x 3.0"
weight5.1 lb

VS325W

Display IconDisplay
pixel number1, 024, 000 (1280 x 800) x 3
color brightness2700 lumens
white brightness2700 lumens
aspect ratio16:10
native resolution1280 x 800 (WXGA)
resize support640 x 480 (VGA), 800 x 600 (SVGA), 1152 x 864 (SXGA), 1280 x 960 (SXGA2), 1280 x 1024 (SXGA3), 1440 x 900 (WXGA+), 1400 x 1050 (SXGA+), 1600 x 1200 (UXGA), 1680 x 1050 WSXGA+
Lamp IconLamp
lamp typeE-TORL 230 W UHE
lamp life (eco mode)5000 hours
lamp life (normal mode)4000 hours
Projection IconProjection
throw ratio range1.30 – 1.56
size (projected distance)33" – 318" (0.84 – 8.08 m)
keystone correctionVertical: Auto ± 30 degrees, Horizontal: easy-slide
Power and Operating IconPower and Operating
power supply voltage100 – 240 V ±10%, 50/60 Hz
power consumption (normal mode)283 W
power consumption (eco mode)234 W
operating temperature41 ˚ to 95 ˚F (5 ˚ to 35 ˚C)
fan noise (normal mode)37 dB
fan noise (eco mode)29 dB
Physical IconPhysical
dimensions (including feet)11.6" x 9.0" x 3.1"
dimensions (excluding feet)11.6" x 9.0" x 3.0"
weight5.1 lb
