Connecting to Computer Sources
Connecting to Video Sources
Connecting to External USB Devices
Connecting to a Document Camera
Parent topic: Setting Up the Projector
Related references
Projector Setup Settings - Extended Menu
Product Box Contents
Connecting to Computer Sources
Follow the instructions in these sections to connect a computer to the projector.
Connecting to a Computer for USB Video and Audio
Connecting to a Computer for VGA Video
Connecting to a Computer for HDMI Video and Audio
Connecting to a Computer for USB Mouse Control
Connecting to a Computer for Sound
Parent topic: Projector Connections
Connecting to a Computer for USB Video and Audio
If your computer meets the system requirements, you can send video and audio output to the projector
through the computer's USB port (preferably USB 2.0). Connect the projector to your computer using a
USB cable.
1. In the projector's Extended menu, set the USB Type B setting to USB Display.
2. Turn on your computer.
3. Connect the cable to your projector's USB TypeB port.
26

Table of Contents

Other manuals for Epson VS220

Preview: Quick Setup
Quick Setup4 pages
Preview: Declaration Of Conformity
Declaration Of Conformity4 pages
Preview: Product Specifications
Product Specifications4 pages

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Epson VS220 and is the answer not in the manual?

Epson VS220 Specifications

VS220

Display IconDisplay
pixel number480, 000 dots (800 x 600) x 3
color brightness2700 lumens
white brightness2700 lumens
aspect ratio4:3
native resolution800 x 600 (SVGA)
resize support640 x 480 (VGA), 1024 x 768 (XGA), 1280 x 800 (WXGA), 1680 x 1050 WSXGA+
Lamp IconLamp
lamp typeE-TORL 230 W UHE
lamp life (eco mode)5000 hours
lamp life (normal mode)4000 hours
Projection IconProjection
throw ratio range1.45 – 1.96
size (projected distance)23" – 350" (0.87 – 10.5 m)
keystone correctionVertical: Auto ± 30 degrees, Horizontal: Manual
Power and Operating IconPower and Operating
power supply voltage100 – 240 V ±10%, 50/60 Hz
power consumption (normal mode)283 W
power consumption (eco mode)234 W
operating temperature41 ˚ to 95 ˚F (5 ˚ to 35 ˚C)
fan noise (normal mode)37 dB
fan noise (eco mode)29 dB
Physical IconPhysical
dimensions (including feet)11.6" x 9.0" x 3.1"
dimensions (excluding feet)11.6" x 9.0" x 3.0"
weight5.1 lb

VS320

Display IconDisplay
pixel number786, 432 (1024 x 768) x 3
color brightness2700 lumens
white brightness2700 lumens
aspect ratio4:3
native resolution1024 x 768 (XGA)
resize support640 x 480 (VGA), 800 x 600 (SVGA), 1280 x 960 (SXGA2), 1280 x 1024 (SXGA3), 1440 x 900 (WXGA+), 1400 x 1050 (SXGA+), 1600 x 1200 (UXGA)
Lamp IconLamp
lamp typeE-TORL 230 W UHE
lamp life (eco mode)5000 hours
lamp life (normal mode)4000 hours
Projection IconProjection
throw ratio range1.48 – 1.77
size (projected distance)30" – 300" (0.76 – 7.62 m)
keystone correctionVertical: Auto ± 30 degrees, Horizontal: easy-slide
Power and Operating IconPower and Operating
power supply voltage100 – 240 V ±10%, 50/60 Hz
power consumption (normal mode)283 W
power consumption (eco mode)234 W
operating temperature41 ˚ to 95 ˚F (5 ˚ to 35 ˚C)
fan noise (normal mode)37 dB
fan noise (eco mode)29 dB
Physical IconPhysical
dimensions (including feet)11.6" x 9.0" x 3.1"
dimensions (excluding feet)11.6" x 9.0" x 3.0"
weight5.1 lb

VS325W

Display IconDisplay
pixel number1, 024, 000 (1280 x 800) x 3
color brightness2700 lumens
white brightness2700 lumens
aspect ratio16:10
native resolution1280 x 800 (WXGA)
resize support640 x 480 (VGA), 800 x 600 (SVGA), 1152 x 864 (SXGA), 1280 x 960 (SXGA2), 1280 x 1024 (SXGA3), 1440 x 900 (WXGA+), 1400 x 1050 (SXGA+), 1600 x 1200 (UXGA), 1680 x 1050 WSXGA+
Lamp IconLamp
lamp typeE-TORL 230 W UHE
lamp life (eco mode)5000 hours
lamp life (normal mode)4000 hours
Projection IconProjection
throw ratio range1.30 – 1.56
size (projected distance)33" – 318" (0.84 – 8.08 m)
keystone correctionVertical: Auto ± 30 degrees, Horizontal: easy-slide
Power and Operating IconPower and Operating
power supply voltage100 – 240 V ±10%, 50/60 Hz
power consumption (normal mode)283 W
power consumption (eco mode)234 W
operating temperature41 ˚ to 95 ˚F (5 ˚ to 35 ˚C)
fan noise (normal mode)37 dB
fan noise (eco mode)29 dB
Physical IconPhysical
dimensions (including feet)11.6" x 9.0" x 3.1"
dimensions (excluding feet)11.6" x 9.0" x 3.0"
weight5.1 lb
