EQUATION COOL 7K 2 - PARTS DESCRIPTION; Control Panel Overview; Remote Control Functions

44
EN
PARTS DESCRIPTION
Control panel
Remote control
Deflectors
Remote Control
receiver
Intake grille + filter
Intake grille
Selecting the
operating mode
Selecting the
operating mode
Adjusting the setpoint
temperature
Adjusting the setpoint
temperature
Fan speed
adjustment
Timer
Setting
Fan speed adjustment
Display setting
Timer Setting
Activating Sleep Mode
On / O
button
On / O button
• Room temperature display
• Setpoint temperature display
Timer active
Air outlet grille
Control
Panel
Plug fixer
Condenser drain
Operating mode
display
