Equinox Systems EQLED136 - DMX Mode Configuration; Accessing and Setting DMX Parameters; DMX 3-Channel Mode Functions; Multi-Channel DMX Functions

www.prolight.co.uk Microbar Multi System User Manual
5
Operating instructions
DMX mode:
OperatinginaDMXcontrolmodeenvironmentgivestheuserthegreatestexibilitywhenitcomes
tocustomisingorcreatingashow.Inthismodeyouwillbeabletocontroleachindividualtraitof
thextureandeachxtureindependently.
ToaccesstheDMXaddressmode,pressthe“MENU”buttonontherearoftheunittoshow
dNxontheLEDdisplay.Nowpressthe“ENTER”buttonandusethe“UP”and“DOWN”
buttonstosettherequiredDMXaddress.Pressthe“ENTER”buttontoconrmthesetting.
Nowusethe“UP”and“DOWN”buttonstochooseoneofthe3/6or15DMXchannelmodes.
Pressthe“ENTER”buttontoconrmthesetting.
Toexitoutofanyoftheaboveoptions,pressthe“MENU”button.




3 channel mode:
Channel Value Function
CH1
000-009 Nofunction
010-049 APXX-Parauto
050-089 AFXX-Effectauto
090-129 ANXX-Par&Effectauto
130-169 SPXX-Parsoundactive
170-209 SFXX-Effectsoundactive
210-255 SNXX-Par&Effectsoundactive
CH2
000-019 AP01/SP01
WhenCH1
is010-049or
130-169
020-039 AP02/SP02
040-059 AP03/SP03
060-079 AP04/SP04
080-099 AP05/SP05
100-119 AP06/SP06
120-139 AP07/SP07
140-159 AP08/SP08
160-179 AP09/SP09
180-199 AP10/SP10
200-219 AP11/SP11
220-239 AP12/SP12
240-255 AP13/SP13
CH2
020-039 AF02/SF02
WhenCH1
is050-089or
170-209
040-059 AF03/SF03
060-079 AF04/SF04
080-099 AF05/SF05
100-119 AF06/SF06
120-255 AF07/SF07
CH2
000-019 AN01/SN01
WhenCH1
is090-129or
210-255
020-039 AN02/SN02
040-059 AN03/SN03
060-079 AN04/SN04
080-099 AN05/SN05
100-119 AN06/SN06
120-139 AN07/SN07
140-159 AN08/SN08
160-179 AN09/SN09
180-255 AN10/SN10
CH3 000-255 Speedadjustment
