www.prolight.co.uk Microbar Multi System User Manual
6
Operating instructions
15 channel mode:
Channel Value Function
CH1 000-255 Red(0-100%)
Effect1
CH2 000-255 Green(0-100%)
CH3 000-255 Blue(0-100%)
CH4 000-255 White(0-100%)
CH5 000-255 Motor
CH6 000-255 Red(0-100%)
Pars1&2
CH7 000-255 Green(0-100%)
CH8 000-255 Blue(0-100%)
CH9 000-255 White(0-100%)
CH10 000-255 Red(0-100%)
Effect2
CH11 000-255 Green(0-100%)
CH12 000-255 Blue(0-100%)
CH13 000-255 White(0-100%)
CH14 000-255 Motor
CH15 000-255 Strobe
Master/slave mode:
Tosettheunitinslavemode,pressthe“MENU”buttonontherearoftheunittoshowSLA
ontheLEDdisplay.Nowpressthe“ENTER”buttontodisplaySLAv.Pressthe“ENTER”
buttontoconrmthesetting.Theunitwillnowruninsequencewiththemasterunit.
Toexitoutofanyoftheaboveoptions,pressthe“MENU”button.
PleaseensurethatallslaveunitsaresettothesameDMXchannelmodeasthemasterunit.
Auto mode:
Toaccesstheautomodes,pressthe“MENU”buttonontherearoftheunittoshowAuto
ontheLEDdisplay.Nowpressthe“ENTER”buttonandusethe“UP”and“DOWN”buttonstochoose
betweenAutP(Par-Auto),AutF(Effect-Auto)orAutN(Par&Effect-Auto).Pressthe“ENTER”
buttontoconrmthesettingandusethe“UP”and“DOWN”buttonstochoosetheautoprogram
betweenAP01~AP13(Par-Auto),AF01~AF07(Effect-Auto)orAn01~An10(Par
&Effect-Auto).Nowpressthe“ENTER”buttonandusethe“UP”and“DOWN”buttonstoselectthe
programspeedbetweenS. 00~S. 32.Finallypressthe“ENTER”buttonandusethe“UP”and
“DOWN”buttonstoselectthemotorspeedbetweenN. 00~N. 09.(Themotorspeedcanonlybe
selectedwheninAutF(Effect-Auto)orAutN(Par&EffectAuto)modes).
Pressthe“ENTER”buttontoconrmthesetting.
Toexitoutofanyoftheaboveoptions,pressthe“MENU”button.
6 channel mode:
Channel Value Function
CH1 000-255 Red(0-100%)
CH2 000-255 Green(0-100%)
CH3 000-255 Blue(0-100%)
CH4 000-255 White(0-100%)
CH5 000-255 Strobe(slow-fast)
CH6 000-255 Motorspeed(slow-fast)
