Technical specications
01-LEDdisplay
02-Menubutton
03-Downbutton
04-Upbutton
05-Enterbutton
06-Poweroutsocket
07-Powerinsocket
08-Fuse5A250V
09-DMXin
10-On/offswitch
11-DMXout
Inthebox:1 x xture,
1 x power cable,
hanging bracket &
1 x user manual
DMX OUTDMX IN
ONOFF
POWER IN/OUT
01 09 100802 04
03 05
11
06
07
MENU DOWN UP ENTER
