Operating instructions
DMX channel selection:
OperatinginDMXcontrolmodegivestheuserthegreatestexibilitywhenitcomestocustomisingor
creatingashow.Inthismodeyouwillbeabletocontroleachindividualtraitofthextureandeach
xtureindependently.
ToaccesstheDMXchannelmode,pressthe“MODE”buttononthefontoftheunittoshowCHnd
ontheLEDdisplay.Nowpressthe“ENTER”buttonandthechannelmodewillbedisplayed.
Usethe“UP”and“DOWN”buttonstochooseoneofthe1,4,7,or10DMXchannelmodes.Pressthe
“ENTER” buttonagain,thiswillsettheDMXchannel.ThedisplaywillnowdisplayAddr.

Toexitoutofanyoftheaboveoptions,pressthe“MODE”button.
1 channel mode:
Channel Value Function
1 0-7 Blackout
8-127 Autorun(AT01)
128-255 Soundactive(128:lowsensitivity,255:highsensitivity)
