Product overview & technical specications
The PIXELpoint multi-beam batten features 40 x 3W 3-in-1 RGB individually controllable LEDs dispensing super
narrow, long throw beams for sharp mid-air effects. The unit is packed with multiple different ows and chases
creating stunning eye candy effects. For full creativity, DMX control can also be utilised via one of the 13 different
channel modes allowing each pixel to be mapped for even more stunning visual effects. Power/DMX linking
provides easy connection of multiple units.
• 40 x 3W tri-colour LEDs (RGB)
• Beam angle: 5°
• 4kHz refresh rate
• Pixel mapping capabilities
• DMX channels: 3/4/6/7/8/12/13/24/25/60/61/120 or 121 selectable
• Static colour, auto, sound active and master/slave modes
• 0-100% dimming
• Variable strobe
• Supplied with mounting bracket
• 4 push button menu with LED display
• powerCON input/output
• 3-Pin XLR input/output
• Fan cooled
PIXELpoint Batten
Specications PIXELpoint Batten
Power consumption 76W
Power supply 100~240V, 50/60Hz
Fuse F1A 250V
Dimensions 55 x 1005 x 145mm
Weight 2.5kg
Order code EQLED059
145mm
1005mm
55mm
85mm
