Technical specications
In the box:
1 x xture
1 x power cable
1 x mounting bracket
& 2 x knobs
02
06
04 0803
07
09
01 - Fuse F1A 250V
02 - powerCON input
03 - powerCON output
04 - 3-Pin XLR input
05 - 3-Pin XLR output
06 - Bracket tightening knobs
07 - Bracket
08 - LED display
09 - Function buttons
10 - Fan
0501
10
