Product overview & technical specications
The Viper projects a wide array of multicoloured beams of light that rotate and twist around the room. 12 white
SMD LEDs sit in 2 horizontal strips on the front of the unit adding a strobe effect for an extra dimension. Control
is facilitated via 2 rotary knobs on the rear, one to select the auto or sound modes and the other for adjusting the
speed/sensitivity settings.
• 3 x 3W tri-colour LEDs (RGB)
• 12 x white 5050 SMD LEDs
• Auto and sound active modes
• Supplied with hanging bracket
• 2 rotary knobs for mode/setting adjustment
• IEC power input
• Convection cooled
Viper
Specications
Power consumption 18W
Power supply 100-240V, 50/60Hz
Fuse F1A 250V
Dimensions 160 x 167 x 177mm
Weight 1kg
Order code EQLED375
25mm
154mm
177mm
137mm
167mm
104mm 56mm
160mm
