17
Figure 17. Bubble Level Indicator.
Figure 19. Decal-Raise or Lower Steering Wheels.
Figure 20. Front Outriggers with Blocking. Figure 21. Rear Outriggers with Blocking.
c. Lower the other set of outriggers
to raise the other end of the machine until
level front to back.
d. Use the appropriate outrigger to
raise the remaining low corner.
e. Make any adjustments using
the appropriate outrigger. Use only small
adjustments.
Never move or adjust the outriggers unless
the dump box is in the transport position.
Always raise the outriggers completely before
moving the Equipter. Lowered outriggers can
get caught on personnel, fences, and shrubs as
the machine passes by.
