Instruction manual for installation and operation of automatic pellet burner “ERATO GP20+”
(Version : 02.02.2010 10:36) p. 38/50
Absence of fuel in
the hopper
The fuel hopper should be
charged. Then manually charge
the fuel transport auger until new
fuel comes out of the exit side of
the auger and back plug its cable
onto the burner’s main unit.
Absence of fuel in
the burner’s
combustion chamber
It is possible by manually
restarting to achieve nominal
operation process of the burner. If
this approach results in stable
ignition, then it is necessary to
increase the transported initial
fuel mass - the adjustment should
be performed by authorized
technician;
Fuel is present in the
b
urner’s grate, but
it’s not ignited or it is
fully incinerated and
the combustion
process has
extinguished, i.e. not
present;
In case that the electric heater is
out of order or not operating, then
it should be replaced (or checked
for proper functioning). In case
that the electric heater is working,
then it is necessary to adjust the
operating parameters and/or the
air flow rate - the adjustment
s
hould be performed by
authorized technician;
6. No fuel ignition
Abnormal operation
or malfunctioning of
the photosensor
The photosensor should be
checked, cleared if necessary
adjusted or replaced in case it is
out of order;
