Part index
The index below refers to Fig. 1 on page 4.
1. Carry handle
2. Power cord with plug
3. Prime/Spray lever
4. Paint outlet
5. Inlet valve
a) Valve clearance button
6. Prime tube
a) Tube clamp
7. Suction tube
a) Tube clamp (x2)
b) Filter net
8. Right bracket
9. Pipe clips (x3)
10. Spray hose
11. Gun swivel joint
12. Grip handle
a) Filter*
13. Trigger lock
14. Spray gun
a) Retaining nut
b) Union part
c) Seal
d) Spray tip
e) Spray tip guard
f) Spray nozzle (type
517)
15. Trigger
16. Trigger guard with
hanging hook
17. Foot support
18. Foot assembly set (x4)
a) Bolt
b) Spring washer*
c) Flat washer*
d) Nut
19. Left bracket
20. Bolt for bracket assembly
(x4)
21. Motor housing
22. Pressure control knob
23. On/Off switch
24. Air vents
25. Spanner (24# & 27#)
26. Spanner (17# & 19#) (x2)
27. Mini Spanner
28. Hex key
29. Cleaning needle
(with protector)
30. Cleaning brush
NOTE: Parts marked with * are not shown in this overview. Please refer
to the respective section in the instruction manual.
