Cleaning of spray hose (10) (Fig. P)
1. After uid in the prime tube (6) is clear, turn the Prime/Spray lever (3) to the spray
mode (Step 1).
2. Rotate the spray tip (14d) 180
o
in clockwise direction to make the spray nozzle
(14f) in the cleaning position (step 2).
3. Fully press the trigger (15) to cycle the water or ushing solvent through the uid
system and spray hose (10) (Step 3).
4. Repeat pressing the trigger (15) to ush the spray hose (10) until the water or
ushing solvent through the prime pipe (6) is clear (Step 4).
03
Mix cleaning of paint passage (Fig. Q)
1. Rotate the spray tip (14d) back to make the spray nozzle (14f) in the spraying
position (step 1)
2. Turn the Prime/Spray lever (3) downward to prime mode to relieve pressure (Step
2).
3. Press the trigger (15) to ush the airless paint sprayer until clear (Step 3).
4. Release trigger (15), switch the product off, disconnect it from the power supply
(Step 4).
04
Cleaning of lter net (7b) (Fig. R)
1. Remove the lter net (7b) from suction tube (7) by squeezing two tabs of the tube
clamp (7a) (Step 1).
2. Pull the lter net (7b) out of suction tube (7) (Step 2) and rinse thoroughly in water.
3. Push lter net (7b) back into suction tube (7) (Step 3).
4. Secure the lter net (7b) by the tube clamp (7a) (Step 4).
05
Cleaning of spray gun (14) (Fig. S)
WARNING! Never use metal or other objects that could damage the holes
in the spray tip and spray nozzle. Never immerse the product completely
in solvent or other liquids.
1. Remove the spray gun (14) from spray hose (10) (Step 1).
2. Remove the spray tip (14d), then completely unscrew the retaining nut (14a) by
the Spanner (27#) (25), remove it together with the spray tip guard (14e) (Step 2).
3. Unscrew the gun swivel joint (11) by the spanner (19#) (26) to remove the grip
handle (12) (Step 3).
