Symbols
On the product, the rating label and within these instructions you will nd among others
the following symbols and abbreviations. Familiarise yourself with them to reduce
hazards like personal injuries and damage to property.
V ~ Volt, (alternating voltage) mm Millimetre
Hz Hertz kg Kilogram
A Ampere ml Millilitre
°C Degree Celsius ml/min Millilitre per minute
psi Pounds per square inch MPa Mega Pascal, pressure unit
bar Pressure unit W Watt
/min or
min
-1
Per minute dB(A) Decibel (A-rated)
m/s² Metres per seconds squared
Protective earth
Lock / to tighten or secure. Unlock / to loosen.
Read the instruction manual. Always wear eye protection.
Always wear ear protection. Wear respiratory protection.
Wear protective gloves. Wear protective, slip-resistant
footwear.
Note / Remark. Caution / Warning.
xxWyy Manufacturing date code; year of manufacturing (20xx) and week of
manufacturing (Wyy)
DIN-sec The time (seconds) taken for the paint to run out of one full viscosity
measuring cup
Switch the product off and disconnect it from the power supply
before assembly, cleaning, adjustments, maintenance, storage and
transportation.
Do not expose the product to rain or wet conditions.
