16
The Li-Ion battery pack (12) is equipped with a power bar (12b) which is used to give
an indication of the battery pack’s remaining capacity. Press the power bar button (12b)
to check battery capacity as . The LED will stay lit for approximately 5 seconds.
charger
Please refer to the charger instruction manual for details about the charging process.
03
WARNING!
product with chain oil before using it! Never operate the product without
chain oil as this will result in extensive damage to the product! Operating
shorten the product life span and cause rapid wear to the saw chain and
guide bar from overheating!
Adequate lubrication of the saw chain during cutting operations is
essential to minimize friction with the guide bar!
Fill chain oil immediately when the oil level is blow “Min”-indicator on the oil level
gauge (14).
1. Position the product in a way that the chain oil tank cap (15) faces upwards.
2. Open the cap and check the oil level. Fill the tank with chain lubrication oil if the oil
level is more than 2 cm below the inside edge of the tank. We recommend using
chain saw. Never use recycled/old oil. Use of non-approved oil will invalidate the
warranty.
3.
edge of the tank to allow for expansion (Fig. C).
4.
04
WARNING! Use only the guide bar and saw chain according which is
saw is completely assembled. Always wear protective gloves!
1. Loosen the clamping knob (19) anticlockwise and remove the drive sprocket
cover (17, Fig. D).
2. Turn the chain tension knob (18) so that the chain tensioning pin (20) moves
towards the drive sprocket (23) all the way to the stop.
