PRODUCT DESCRIPTION
1. Sprocket wheel
2. Lubrication hole
3. Saw chain
4. Guide bar
5. Ridged bumper
6. Front hand guard
7. Front handle
8. Lock-off button
9. Rear handle
10. Switch trigger
11. Air inlets
12. Battery packs (x2) *
a. Release button*
b. Power bar button*
13. Air outlet
14. Oil level gauge
15. Chain oil tank cap
16. Guide bar cover
17. Drive sprocket cover
18. Chain tension knob
19. Clamping knob
20. Chain tensioning pin
21. Positioning pin
22. Thread hole
23. Drive sprocket
24. Fastening bolt
25. Oiling port
26. Chain direction indicator
27. Positioning hole
Parts marked with * are not included.
