Erbauer ERB239MSW - KNOW YOUR SLIDING MITRE SAW

ERBAUER 254MM (10”) DOUBLE BEVEL SLIDING MITRE SAW
KNOW YOUR SLIDING MITRE SAW
Fig 1
1. DUST BAG
2. UPPER BLADE GUARD
3. CUTTING HANDLE
4. LOWER BLADE GUARD
5. BLADE
6. TABLE INSERT
7. MITRE HANDLE
8. LASER GUIDE
9. BASE
10. TURNTABLE
11. LEFT EXTENSION TABLE
12. FENCE
13. HOLD-DOWN CLAMP
14. SLIDE CARRIAGE LOCK KNOB
6
1
3
12
10
14
2
4
7
8
9
11
5 13
