Erbauer ERB2504SE - Stand Assembly Procedure

ERBAUER 250MM TABLE SAW
ERBAUER 250MM TABLE SAW
ERBAUER 250MM TABLE SAW
ERBAUER 250MM TABLE SAW
2
.
Stand assembly
1)
Attach four legs (1) to stand base assembly
(2) using hex bolts (3) washers (4) and nuts (5).
Note:
D
o not tighten bolts until stand is properly alig
ned
(see step #3 before tightening).
2
)
Insert foot pad (6) into bottom of leg. Repeat
for the other two legs as shown.
3) Carefully set the saw in its upright position on
a clean level
surface and adjust the adjustable
foot pad (7), so all legs are contacting the fl oor
and are at similar angles to the fl oor, and tighten
all bolts (See fi g. 2).
Note:
To avoid rocking, t
ighten
all
bolts
.
4) Thread the long screw (8) through the hole (9)
on foot pad (10) to fasten the stand
(
See
fi g.
2-1
)
.
Note:
T
he
tools
to m
ount thi
s saw is not
supplied w
ith th
e saw.
Description
Size
QTY
hex bolt (3)
M6*1.0-45
8
washer (4)
φ6*18-1.5
16
nut (5)
M6*1.0 T=4
8
1
4
2
7
7
Fig 2
