Cleaning and maintenance
38
5.8 Instructions for replacing the lamps
The UV effect of the lamps and thus the tanning effect decreases over the
course of time. Therefore, the replacement intervals specified in the mainte-
nance plan must be adhered to.
5.8.1 Low pressure lamps
y Replace faulty UV low pressure lamps immediately.
y Always replace the entire set of lamps after the specified operating time.
– Turn 90° and carefully remove from the socket.
– UV low pressure lamps possess a reflector which directs the light out-
wards. The lamps must be mounted in such a way that the rear side of
the reflector is located on the device side.
– Push the pins vertically into the socket from above.
– Turn the lamp 90°.
The lettering must be oriented towards the outside (i.e. towards the user).
