Cleaning and maintenance
46/58
4.10 Cleaning or replacing the lamps on
the right
Acrylic glass panels unusable due to soiling!
Soiling on the panels is burned in by the hot lamps and
results in the long term in unserviceable panels.
– Remove fingerprints, cleaning residues and other soil-
ing carefully.
– Remove the screw.
– Fold down the clamping strip.
– Use the suction cup to pull out the panel from the guide.
– Remove the panel to the side and carefully place it to one side.
– Remove the screws and then remove the lamp cover.
Replacing lamps:
Pressure lamps: see page 43.
The assembly is the same process in reverse order.
Danger of crushing fingers when folding the clamping
strip!
Fingers can be crushed when folding the clamping strip.
– Do not hold fingers between the clamping strip and
acrylic glass panel when folding.
