Cleaning and maintenance
02/2021 1026110-00 Operating instructions – 47/58
4.11 Cleaning or replacing interior lighting
– Using suction cups, pull the lamp cover in the upper area from the panel
and remove.
Replacing lamps:
Low pressure lamp: see page 43.
The assembly is the same process in reverse order.
When assembling the device please note:
– Press in the sides of the lamp cover a little and insert into the panel from
the bottom to the top.
– Check for tight fit.
4.12 Changing the AROMA canister
– Remove the screw.
– Remove the cover.
– Remove the AROMA canister.
