15
With the bases in their desired location, slightly loosen both legs
and frame.
Slide side (a) of the connecting strap onto leg bolt. Swing the
strap and connect side (b) to the leg bolt. Secure the strap by
shifting to the left.
Re-tighten legs. Do not over tighten. Use the remaining strap and
repeat on other end of the base.
STEP 2STEP 1
STEP 3
connecting strap (optional)
a
b
Connecting straps are secured to the base frame upon delivery.
Legs are required for the installation of the connecting straps.
