16
headboard bracket installation guide (optional)
STEP 1
STEP 2
STEP 3
STEP 4
STEP 5
STEP 6
Make sure the bottom
of the base is facing up.
Accessories for
installation:
2 ower bolts,
1 short bolt, 1 nut
Lay the bracket at on the corner of
the base. Make sure to align the leg
hole and the small bolt hole on the
bottom corner of the bracket.
Use the ower bolts to secure
the headboard to the bracket.
a) Thread the leg into the main hole, and twist to tighten. Do not
over tighten.
b) Using short bolt and nut, secure the out edge of bracket.
Align the headboard with the bracket, and slide the headboard on
to the bracket track.
Complete steps 3-6 for other side
of the base.
