1. Step
Switch on the control unit key as
described under point 6.2
2. Step
Set the operating mode switch (3)
to position “B“
(green LED flashes / green and
yellow LED are flashing if the
battery is not fully charged)
6
6.7 Changing strap coil
3. Step
You can use the joystick (8) to position the ChainLance so that the red chain
link is in the middle of the sliding window (6).
The sliding windows must be closed during this operation!
4. Step
Open the sliding window (6). (red LED flashes quickly).
The control unit automatically switches off for safety reasons when the
sliding window is open. Additionally, the main switch (11) has to be turned
to the left into pos. „0“.
3
Fig. 18
Fig. 19
- 28 -
8
11
