ErgoPack 700 - Page 39

16. Step
Open the eccentric latch in the
red head piece of the
ChainLance by pushing it
inwards with your finger.
17. Step
Now hold the strap
vertically so that the
strap and the
ChainLance are
straight.
Push the strap from the back through
the head piece of the ChainLance (as
shown). The strap must pass
between the two aluminium
eccentrics.
Fig. 43
Fig. 42
Fig. 44
- 39 -
Fig. 42
