4.) Insert the plug of the 36V charger (16a) into the socket (15a) of the battery
pack.
Fig. 15
3.) Disconnect the plug (13a) from the battery pack (14a) and let the cable
hang freely down.
13a
14a
Fig. 13 Fig. 14
-23-
Fig. 16
15a 16a 15b
Warning!
Charge the battery pack only with the ErgoPack 36V charger through the
charging socket!
Attention!
Replace always defective flat fuses (15b) of the battery pack (see Fig.15) by a
new one of the same type (vehicle blade fuse 30A / 80V).
If necessary, contact your ErgoPack service partner.
