The device is adapted for 230 V, 50 Hz alternating power supply through a wire equipped
with a plug.
ATTENTION: If the device is equipped with power cable with a plug,
then it is necessary to insert it only to a socket with a protective pin!
Electrical socket must be equipped with protective pin (earthing) and
secured with suitable 15 [A] time delay cut-out.
NOTE: only one device may be connected to a single fuse.
ATTENTION: The device should not cover the socket to which it is
connected!
NOTE: All other electrical connections must be provided by authorised
and qualified personnel and these must be compliant with all general
(EU) and local (national) regulations; non-compliance may lead to
electrical shock or even fatal accidents.
Fig. 3 Location of electrical box.
