3.2.2. Refrigerating system
The device is fitted with an independent cooling system in the form of a monoblock
that does not require any additional soldering operations.
Attention: Prior to tube soldering check if these are free from
impurities/filings, which may later disrupt the device's operation.
Attention: Soldering tubes to one another in order to stiffen the run of
a pipeline is forbidden. In order to stiffen these tubes, a tape or
clamping strips shall be applied.
Note: the refrigerating system may be assembled only by the
manufacturer of this device or qualified personnel.
Note: the system led from the device located on the conduit coming from
the evaporator is equipped with a service valve; the second conduit that
feeds the evaporator is soldered.
3.2.3. Sanitary system
The device is not equipped with a condensate removal system. Condensate is
evaporated by means of hot gas.
3.3. Assembly of the
monoblock
Multicooler 60
Place and screw down the cooling
monoblock.
