ES SYSTEM K 60 - Page 20

Protect the monoblock against
shifting by means of locking
devices.
Perform the following steps for each
monoblock:
1. Screw down the roof
of the monoblock to the
top side extensions.
2. Screw down the cover of the
condenser to the roof.
3. Attach the rear masking
cover of the top side extension
to the brackets of the top side
extension.
