CAUTION: Do not make 10A current measurements for longer than
30 seconds. Exceeding 30 seconds may cause damage to the
meter and/or the test leads.
1. Insert the black test lead banana plug into the
negative COM jack.
2. For current measurements up to 4000µA
AC/DC, set the function switch to the µA
position and insert the red test lead banana
plug into the µA/mA jack and press mode
button to select AC or DC.
3. For current measurements up to 400mA
AC/DC, set the function switch to the mA
position and insert the red test lead banana
plug into the µA/mA jack and press mode
button to select AC or DC.
4. For current measurements up to 10A AC/DC,
set the function switch to the 10A position and insert the red test
lead banana plug into the 10A jack and press mode button to
select AC or DC.
5. Remove power from the circuit under test, then open up the
circuit at the point where you wish to measure current.
6. Touch the black test probe tip to the negative side of the circuit.
Touch the red test probe tip to the positive side of the circuit.
7. Apply power to the circuit.
8. Read the current on the display.
RESISTANCE MEASUREMENTS
