ES TMX-589 - Frequency Specifications; Temperature and Diode Test Specs

19
40.00 Hz
0.01Hz
400.0 Hz
0.1Hz
4.000KHz
1 Hz
40.00kHz
10Hz
400.0kHz
100Hz
+1.0% of rdg + 3 digits
10.00MHz
1kHz
+1.2% of rdg + 4 digits
Sensitivity: >0.5V RMS while ≤1MHz ;
Sensitivity: >3V RMS while >1MHz ;
Input Protection: 1000V dc or 1000V ac rms.
TEMPERATURE
Range
Resolution
Accuracy
-20
o
C~+760
o
C
1
o
C
+3% of rdg +5 digits
-4
o
F~+1400
o
F
1
o
F
+3% of rdg +8 digits
Sensor: Type K Thermocouple
Overload protection: 1000V dc or ac rms..
DIODE TEST
Test current
Resolution
Accuracy
1Ma typical/Open
MAX.3V
1 mV
+10% of rdg + 5 digits
Open circuit voltage: MAX. 3V dc
Overload protection: 1000V dc or ac rms.
AUDIBLE CONTINUITY
Audible threshold: Less than 35Ω Test current MAX. 1.5mA
Overload protection: 1000V dc or ac rms.
Enclosure Double molded, waterproof
Shock (Drop Test) 6.5 feet (2 meters)
Diode Test Test current of 0.9mA maximum, open
circuit voltage 2.8V DC typical
