3 INSTALLATION
3.1 General
The installation must be executed by a professional.
WARNING
Rotating parts can cause injury, take great care.
3.2 Mounting
3.2.1 Welding Head
The welding head can be mounted on a beam-travelling carriage or on a welding col-
umn and boom unit by way of four M12 screws.
N.B.
Make sure the bolts do not touch the bottom of the insulator, which has a thread
depth of 14 mm.
3.2.2 A6 Slide
For mounting/ dismounting of A6 Slide, see instruction manual 0443 394 xxx.
This safety sign is placed on the cover of the vertical slide.
