- 45 -
* #>#;
Item
no.
Qty Ordering no. Denomination Notes
0416967880 Welding head A6 Compact 500 (A6-SFE1C)
1 8 0278300180 Insulator 2000 V.
2 2 0334333880 Motorised slide A6 Slide (l=60), see separate manual
3 1 0153856884 Flux hopper with flux valve 1 l
4 1 0254900880 Flux funnel
5 1 0145063896 Motor with gear A6 VEC (4000rpm, 156:1), see separate manual
6 1 0449253882 Cable unit L =5
6:2 1 0456490883 Motor cable 5.0m
63 1 0456504884 Cable (arc-voltage) 5m
7 1 0218810183 Insulated hand wheel
8 1 0147639889 Wire straightener (right mounted) D35
18 1 0417959886 Contact device hd l=180
20 1 0334170001 Clamping ring
21 1 0334171001 Plate
22 1 0334172001 Gear bracket
25 4 0212204527 Stop screw SK6SS
27 1 0411408001 Mounting plate
30 1 0416955001 Attachment for roller
31 1 0153148880 Pressure roller
32 1 0332411880 Stub shaft with washer
37 0443383001 Flux hose d32/25
38 1 0416957001 Wire conduit mount
80 1 0457713001 Bar
86 1 0806265880 Bracket
88 1 0811053001 Bracket
