ESAB A6S Arc Master - Page 46

- 46 -
 (**#(
Item
Qty Orderingno. Denomination Remarks
0154465880 Slide, manually operated L=90
1 1 0154464001 Slide frame
6 1 0154463880 Carriage with slide rails
7 6 0190509485 Stop screw M10x10
8 1 0154458001 End piece
10 2 0211102957 Roll pin D5x20
11 1 0154461001 Lead screw
16 1 0190531201 Ball bearing SKF 3201
17 1 0154456001 Lock nut
18 1 0154457001 Ball bearing cap
22 1 0334537001 Handle crank
23 1 0211102938 Roll pin D3x20
0154465881 Slide, manually operated
2 1 0154464002 Slide frame
6 1 0154463880 Carriage with slide rails
7 6 0190509485 Stop screw M10x10
8 1 0154458001 End piece
10 2 0211102957 Roll pin D5x20
12 1 0154461002 Lead screw
16 1 0190531201 Ball bearing SKF 3201
17 1 0154456001 Lock nut
18 1 0154457001 Ball bearing cap
22 1 0334537001 Handle crank
23 1 0211102938 Roll pin D3x20
