ESAB A6S Arc Master - Page 47

- 47 -
#; ; (
Item
Qty Orderingno. Denomination Remarks
0671171580 Angular slide
1 1 0232601901 Housing (casing)
2 1 0232303101 Worm wheel
3 1 0040644080 Worm screw
4 1 0215401206 Locking washer D25
5 1 0215401306 Nut
6 1 0218522301 Eccentric bushing
7 1 0215100204 Washer D36/13x6
8 1 0212101628 Screw M12x30
9 1 0212911101 Screw
10 1 0212204346 Stop screw M5x12
