ESAB A6S Arc Master - Page 48

- 48 -
 *;#+>
Item
no.
Qty Ordering no. Denomination Notes
0147639880 Wire straightener(right mounted)
1 1 0156449001 Clamp
4 1 0215503601 Insulating sleeve
5 1 0156530001 Clamp half D35
6 2 0212900001 Spacer screw
7 4 0215201209 Sealing, O-ring D11.3x2.4
8 2 0218400801 Pressure roller arm
9 1 0218810181 Handwheel, insulated
10 1 0218810182 Handwheel, insulated
11 3 0332408001 Stub shaft
13 3 0153148880 Pressure roller
14 1 0415498001 Pressure roller, upper
15 2 0212902601 Spacer screw
16 1 0415499001 Pressure roller, lower
19 2 0219501013 Spring washer D18.1/10.2
28 1 0156531001 Clamp half D35
30 1 0212 601110 Nut M10
