C. RATING OF AK 400 / AK 600 THYRISTORISED MIG/MAG
WELDING POWER SOURCES
CHARACTERISTICS
CONSTANT POTENTIAL TYPE
INPUT:
SUPPLY VOLTAGE, PHASE
& FREQUENCY
415 V ± 10%, 3 PHASE, 50 HZ, AC
MAXIMUM INPUT CURRENT 31 Amps 55 Amps
MAXIMUM RATING 20.7 KVA 40 KVA
OUTPUT:
OUTPUT CURRENT RANGE DC 60A-400A DC 60A-600A
Maximum output Current at
60% Duty Cycle
400 Amps 600 Amps
Maximum continuous current
at 100% Duty cycle
310 Amps 470 Amps
Open circuit voltage (Max) 53 Volts DC 63 Volts DC
Type of Welding Voltage &
Current control
Stepless through remote control
Unit RC AUTO K 400 &
RC AUTO K 600
Class of Insulation
CLASS H
COOLING FORCED AIR COOLED
Approximate dimension
(LENGTH X WIDTH X
HEIGHT) in mm
675X 350 X 690 617 X 455 X 850
Weight (Approximate) 110 Kgs. 155 Kgs.
